Steel Truss Dock Frames
Engineered for exceptional strength and longevity, American Muscle Docks steel truss frames are constructed from sturdy 1.5" x 1.5" x 3/16" steel angle, strategically separated by 1/2" diagonal round bar to create a highly rigid box frame structure. For added reinforcement, corner gussets are incorporated at all four top corners.
These frames are designed for easy assembly and customization, featuring prepunched holes along the sides and ends to facilitate seamless side-to-side and end-to-end connections using standard 1/2" x 1.5" hex head bolt sets (sold separately). The top of each frame is also prepunched, providing flexibility for attaching your decking either directly to the frame or via optional nailer strips. This design allows for versatile decking options to suit your specific needs.
- 1.5" and 2" Angle options available
- Custom sizes available
Original: $592.00
-65%$592.00
$207.20
Description
Engineered for exceptional strength and longevity, American Muscle Docks steel truss frames are constructed from sturdy 1.5" x 1.5" x 3/16" steel angle, strategically separated by 1/2" diagonal round bar to create a highly rigid box frame structure. For added reinforcement, corner gussets are incorporated at all four top corners.
These frames are designed for easy assembly and customization, featuring prepunched holes along the sides and ends to facilitate seamless side-to-side and end-to-end connections using standard 1/2" x 1.5" hex head bolt sets (sold separately). The top of each frame is also prepunched, providing flexibility for attaching your decking either directly to the frame or via optional nailer strips. This design allows for versatile decking options to suit your specific needs.
- 1.5" and 2" Angle options available
- Custom sizes available
